FB49 TECH SPECS
VESA800X500 FLAT BRACKET
Our FB49 low profile flat bracket is one of the most discreet and easy to fit display wall mounts available on the market. Ideal for mounting screens from 49” to 80”, the FB49 features a simple hook on/hook off mounting system, as well as marine/security locking as standard.
- Low 30mm (1.2”) profile for discreet mounting
- Solid Steel construction for strength
- VESA compatible up to VESA800x500
- Supplied with marine/security locking system
DISCREET
SIMPLE
Suitable for residential, commercial and indoor marine installations as standard, the FB49 can mount screens with VESA mounting patterns from VESA75 to VESA800x500, with a maximum display weight limit of up to 70kg. The supplied security locking bar enables integrators to secure the bracket in place after fitting, either for stability in indoor marine applications or security in residential/commercial applications. Fitting is quick and easy thanks to the FB49’s hook on/hook off screen mount, while the brackets slim profile helps provide a discreet mounting solution.
DESIGNED WITH DEALERS IN MIND
TECHNICAL SPECIFICATION
| PRODUCT CODE | FB49 |
|---|---|
| BOLT PATTERN (VESA) | UP TO 800 X 500 |
| DEPTH FROM WALL | 30MM (1.18") |
| FINISH | BLACK PAINT |
| MAX WEIGHT | 70KG (154LBS) |
| MOVEMENT TYPE | FIXED |
| SCREEN SIZES (APPROX) | 49" - 80" |
| SHIPPING INFORMATION | |
| SHIPPING DIMENSIONS | 91 x 13 x 5cm (3.58 x 0.51 x 0.19") |
| SHIPPING WEIGHT | 4kg (11lbs) |
| DOWNLOADS / SUPPORT | |
| TECHNICAL SHEET |
 FB49 TECH
FB49 SELL SHEET
|
| INSTRUCTIONS |
FB49 INSTRUCTIONS
|
| CAD |
 FB49 CAD
|
