LSL TECH SPECS

TV LIFT 19"-40"

The LSL is a compact but versatile TV lift, available in 3 different sizes, ideal for smaller screens.

PRODUCT APPROX TV SIZE MAX SCREEN HEIGHT
LSL1 19-32" 410MM (16.14")
LSL2 32-40" 524MM (20.62")
LSL3 40" 599MM (23.58")

Compatible with all major home automation control standards, such as Crestron, AMX and Lutron, the LSL is perfect for integrating into a smart home environment.

For larger screens between 42"-79", please see our LSM. For screens larger than 79", speak to our team about our customisable LSH.

Supplied as standard with box enclosure and push flap fixings to enable either option.


Box Enclosure

Push Flap

  • Quick and quiet 24V DC motor
  • Supplied with IR, Contact Closure and RS232 control options
  • Integrated cable management

CONCEAL

REVEAL

Designed and engineered in-house, our Lift System Light is the smallest mechanism in our lift system range and is ideal for concealing and raising smaller TVs in areas such as kitchen islands, home offices or commercial boardrooms. The option to choose between the BE Fixed Lid, PF Push Up Lid or EFA Electric Lid gives installers and end user the freedom to integrate the Light System Light into their environment any way they wish.

Installation and control of the Lift System Range is easy as all Lift System Range mechanisms are supplied ready to install, with no self-assembly required, and feature IR, Contact Closure and RS232 control options as standard.

Control Board

HAND CRAFTED IN HOUSE

Manufacturing Image 1
Manufacturing Image 2 Manufacturing Image 3
Manufacturing Image 4

TECHNICAL SPECIFICATION

PRODUCT CODE LSL1 LSL2 LSL3
CONTROL BOX DIMENSIONS 150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
CONTROL OPTIONS RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE) RS232 / CONTACT CLOSURE / IR (RF AVAILABLE)
DECIBEL RATING 58DB 58DB 58DB
FINISH (CUSTOM AVAILABLE) BLACK PAINT - RAL 9005 BLACK PAINT - RAL 9005 BLACK PAINT - RAL 9005
INTERNAL CABINET HEIGHT 580MM (22.83") 694MM (27.32") 769MM (30.27")
LID TYPE BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED
MAX LIFTING CAPACITY 25KG (55LBS) 25KG (55LBS) 25KG (55LBS)
MAX LIFTING CAPACITY (MARINE) 16KG (35LBS) 16KG (35LBS) 16KG (35LBS)
MAX SCREEN HEIGHT 410MM (16.14") 524MM (20.62") 599MM (23.58")
MOVEMENT TYPE MOTORISED MOTORISED MOTORISED
OUTPUT POWER SUPPLY YES(12V) YES(12V) YES(12V)
POWER CONSUMPTION 250 - 500W 250 - 500W 250 - 500W
POWER SUPPLY 240V OR 110V 240V OR 110V 240V OR 110V
SCREEN SIZES (APPROX) 19-32" 32-40" 40"
SHIPPING INFORMATION
SHIPPING DIMENSIONS 92 x 55 x 25cm (36.22 x 21.65 x 9.84") 92 x 55 x 25cm (36.22 x 21.65 x 9.84") 105 x 55 x 25cm (41.33 x 21.65 x 9.84")
SHIPPING WEIGHT 15kg (33lbs) 18kg (40lbs) 20kg (44lbs)
DOWNLOADS / SUPPORT
TECHNICAL SHEET PDF DocumentLSL1 TECH
PDF DocumentLSL2 TECH
PDF DocumentLSL3 TECH
INSTRUCTIONS PDF DocumentLSL INSTRUCTIONS
CAD CAD FileLSL-BE1 CAD
CAD FileLSL-PF1 CAD
CAD FileLSL-BE2 CAD
CAD FileLSL-PF2 CAD
CAD FileLSL-BE3 CAD
CAD FileLSL-PF3 CAD
TECHNICAL SPECIFICATION
CONTROL BOX DIMENSIONS LSL1 150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
LSL2 150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
LSL3 150 X 210 X 50MM
(5.9 X 8.26 X 1.96")
CONTROL OPTIONS LSL1 RS232 / CONTACT CLOSURE / IR (RF AVAILABLE)
LSL2 RS232 / CONTACT CLOSURE / IR (RF AVAILABLE)
LSL3 RS232 / CONTACT CLOSURE / IR (RF AVAILABLE)
DECIBEL RATING LSL1 58DB
LSL2 58DB
LSL3 58DB
FINISH (CUSTOM AVAILABLE) LSL1 BLACK PAINT - RAL 9005
LSL2 BLACK PAINT - RAL 9005
LSL3 BLACK PAINT - RAL 9005
INTERNAL CABINET HEIGHT LSL1 580MM (22.83")
LSL2 694MM (27.32")
LSL3 769MM (30.27")
LID TYPE LSL1 BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED
LSL2 BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED
LSL3 BOX ENCLOSURE & FIXED LID OPTIONS SUPPLIED
MAX LIFTING CAPACITY LSL1 25KG (55LBS)
LSL2 25KG (55LBS)
LSL3 25KG (55LBS)
MAX LIFTING CAPACITY (MARINE) LSL1 16KG (35LBS)
LSL2 16KG (35LBS)
LSL3 16KG (35LBS)
MAX SCREEN HEIGHT LSL1 410MM (16.14")
LSL2 524MM (20.62")
LSL3 599MM (23.58")
MOVEMENT TYPE LSL1 MOTORISED
LSL2 MOTORISED
LSL3 MOTORISED
OUTPUT POWER SUPPLY LSL1 YES(12V)
LSL2 YES(12V)
LSL3 YES(12V)
POWER CONSUMPTION LSL1 250 - 500W
LSL2 250 - 500W
LSL3 250 - 500W
POWER SUPPLY LSL1 240V OR 110V
LSL2 240V OR 110V
LSL3 240V OR 110V
SCREEN SIZES (APPROX) LSL1 19-32"
LSL2 32-40"
LSL3 40"
SHIPPING DIMENSIONS
SHIPPING DIMENSIONS LSL1 92 x 55 x 25cm (36.22 x 21.65 x 9.84")
LSL2 92 x 55 x 25cm (36.22 x 21.65 x 9.84")
LSL3 105 x 55 x 25cm (41.33 x 21.65 x 9.84")
SHIPPING WEIGHT LSL1 15kg (33lbs)
LSL2 18kg (40lbs)
LSL3 20kg (44lbs)
